Versapix RS
Ayrton
#781Short Name: VERSAPIXRS
“Ayrton Versapix RS is a curved linear static beam bar with 5x 40W RGBW LEDs and ultra-narrow 3.5° optics.”
Physical
Weight8.8 kg
Length676 mm
Width285 mm
Height130 mm
IP RatingIP20
Temp Low-10°C
Temp High45°C
Electrical
Power Consump.220 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorpowerCON, XLR5, etherCON
Optical & Wheels
SourceBar / Batten
Emitters5x 40W RGBW LED Engine (Curved Array)
Lumens4,000 lm
CRI85
Zoom Min3.5°
Zoom Max3.5°
Color Wheels1 [25]
Gobo Wheels---
Movement
Pan Range---
Tilt Range---
Capabilities
PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel
DMX Modes
Basic (6 ch)6 ch
Standard (13 ch)13 ch
Extended (29 ch)29 ch
