Versapix 100
Ayrton
#780Short Name: VERSAPIX100
“Ayrton Versapix 100 is a modular static linear LED batten with 8x 15W RGBW LEDs delivering 3000 lumens.”
Physical
Weight8.2 kg
Length582 mm
Width283 mm
Height330 mm
IP RatingIP20
Temp Low-10°C
Temp High45°C
Electrical
Power Consump.160 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorpowerCON, XLR5, etherCON
Optical & Wheels
SourceBar / Batten
Emitters8x 15W RGBW LED Engine (Static Linear Batten)
Lumens3,000 lm
CRI85
Zoom Min23°
Zoom Max23°
Color Wheels1 [30]
Gobo Wheels---
Movement
Pan Range---
Tilt Range---
Capabilities
PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel
DMX Modes
Mode 1 (4 ch)4 ch
Mode 2 (5 ch)5 ch
Mode 3 (12 ch)12 ch
Mode 7 (32 ch)32 ch
Mode 8 (33 ch)33 ch
Mode 9 (40 ch)40 ch
