MagicDot SX
Ayrton
#756Short Name: MAGICDOTSX
“Ayrton MagicDot SX is a compact moving head with a 60W RGBW LED, 5° to 40° zoom, and continuous pan/tilt rotation.”
Physical
Weight5.7 kg
Length210 mm
Width210 mm
Height330 mm
IP RatingIP20
Temp Low-10°C
Temp High45°C
Electrical
Power Consump.130 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorpowerCON, XLR5, etherCON
Optical & Wheels
SourceBeam
Emitters1x 60W RGBW LED Engine
Lumens1,500 lm
CRI85
Zoom Min5°
Zoom Max40°
Color Wheels1 [21]
Gobo Wheels---
Movement
Pan Range540°
Tilt Range270°
Capabilities
PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel
DMX Modes
Basic (16 ch)16 ch
Standard (19 ch)19 ch
