Levante
Ayrton
#749Short Name: LEVANTE
“Ayrton Levante is a compact 300W LED wash/Fresnel luminaire with 4-blade framing shutters, 6.9° to 57° zoom, and 20000 lumens output.”
Physical
Weight22 kg
Length347 mm
Width210 mm
Height580 mm
IP RatingIP20
Temp Low-10°C
Temp High45°C
Electrical
Power Consump.550 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorpowerCON, XLR5, etherCON
Optical & Wheels
SourceWash
Emitters300W White LED Engine (Wash/Fresnel)
Lumens20,000 lm
CRI70
Zoom Min6.9°
Zoom Max57°
Color Wheels1 [8]
Gobo Wheels1 [8]
Movement
Pan Range540°
Tilt Range270°
Capabilities
PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel
DMX Modes
Basic (29 ch)29 ch
Standard (31 ch)31 ch
Extended (50 ch)50 ch
