Jolt Bar FX
ADJ
#360Short Name: Jolt Bar FX
“1-meter professional linear LED wash and strobe batten featuring 448x 0.3W RGB LEDs and 112x 5W cool white SMD LEDs delivering 15,000 lumens with 32 RGB zones and 16 white zones.”
Physical
Weight6.3 kg
Length1000 mm
Width107 mm
Height123 mm
IP RatingIP20
Temp Low-10°C
Temp High45°C
Electrical
Power Consump.430 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorpowerCON, XLR 5-pin
Optical & Wheels
SourceBar / Batten
Emitters448x 0.3W RGB SMD LEDs + 112x 5W Cool White SMD LEDs
Lumens15,000 lm
CRI85
Zoom Min116°
Zoom Max116°
Color Wheels---
Gobo Wheels---
Movement
Pan Range---
Tilt Range---
Capabilities
PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel
DMX Modes
6 Channel6 ch
9 Channel9 ch
13 Channel13 ch
16 Channel16 ch
18 Channel18 ch
32 Channel32 ch
32A Channel32 ch
38 Channel38 ch
43 Channel43 ch
64 Channel64 ch
78 Channel78 ch
112 Channel112 ch
127 Channel127 ch
