Focus Spot 6Z
ADJ
#338Short Name: Focus Spot 6Z
“High-power 300W cool white LED spot moving head fixture with motorized zoom (9° to 28°), motorized focus, motorized iris, 2 color wheels, 2 rotating gobo wheels, and dual prisms.”
Physical
Weight19.4 kg
Length320 mm
Width234 mm
Height560 mm
IP RatingIP20
Temp Low-15°C
Temp High45°C
Electrical
Power Consump.380 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorpowerCON TRUE1, XLR 5-pin, XLR 3-pin, RJ45
Optical & Wheels
SourceSpot
Emitters1x 300W Cool White LED Engine
Lumens11,000 lm
CRI---
Zoom Min9°
Zoom Max28°
Color Wheels2 [Wheel 1: 7 Dichroic Colors + White, Wheel 2: 7 Dichroic Colors + White]
Gobo Wheels2 [Wheel 1: 7 Rotating Gobos + Open, Wheel 2: 7 Rotating Gobos + Open]
Movement
Pan Range540°
Tilt Range270°
Capabilities
PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel
DMX Modes
Basic21 ch
Standard25 ch
Extended29 ch
