Focus Profile
ADJ
#335Short Name: Focus Profile
“Feature-rich 400W LED profile moving head fixture with full subtractive CMY color mixing, variable CTO, full blackout framing shutters, motorized zoom (7° to 45°), and animation wheel.”
Physical
Weight27.75 kg
Length400 mm
Width260 mm
Height651 mm
IP RatingIP20
Temp Low-25°C
Temp High45°C
Electrical
Power Consump.560 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorpowerCON TRUE1, XLR 5-pin, XLR 3-pin, RJ45
Optical & Wheels
SourceProfile
Emitters1x 400W Cool White (6700K) LED Engine
Lumens20,990 lm
CRI70
Zoom Min7°
Zoom Max45°
Color Wheels1 [6 Dichroic Colors + Open]
Gobo Wheels2 [Wheel 1: 7 Rotating Glass, Wheel 2: 8 Static Metal]
Movement
Pan Range540°
Tilt Range270°
Capabilities
PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel
DMX Modes
Basic36 ch
Standard40 ch
Extended51 ch
