ElectraPix Bar 16
ADJ
#303Short Name: ElectraPix Bar 16
“IP65-rated battery-powered 1-meter linear wash fixture featuring sixteen 20W RGBAL+UV primary LEDs and 66 RGB background LEDs with Aria X2 wireless control.”
Physical
Weight10.9 kg
Length1164 mm
Width86 mm
Height191 mm
IP RatingIP65
Temp Low-20°C
Temp High45°C
Electrical
Power Consump.90 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorpowerCON TRUE1, XLR 5-pin
Optical & Wheels
SourceBar / Batten
Emitters16x 20W Hex (RGBAL+UV) LEDs + 66x 0.2W RGB Background LEDs
Lumens---
CRI84
Zoom Min17°
Zoom Max17°
Color Wheels---
Gobo Wheels---
Movement
Pan Range---
Tilt Range---
Capabilities
PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel
DMX Modes
66 Channel66 ch
5 Channel5 ch
6 Channel6 ch
9 Channel9 ch
13 Channel13 ch
22 Channel22 ch
24 Channel24 ch
48 Channel48 ch
52 Channel52 ch
