7PZ IP
ADJ
#292Short Name: 7PZ IP
“Heavy-duty IP65 outdoor LED par luminaire with motorized 5° to 45° zoom, powered by seven 15W quad RGBW LEDs.”
Physical
Weight11 kg
Length270 mm
Width350 mm
Height380 mm
IP RatingIP65
Temp Low-15°C
Temp High45°C
Electrical
Power Consump.128 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorpowerCON TRUE1, XLR 5-pin
Optical & Wheels
SourcePAR
Emitters7x 15W Quad (RGBW: 4-in-1) LEDs
Lumens---
CRI---
Zoom Min5°
Zoom Max45°
Color Wheels---
Gobo Wheels---
Movement
Pan Range---
Tilt Range---
Capabilities
PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel
DMX Modes
12 Channel12 ch
13 Channel13 ch
5 Channel5 ch
6 Channel6 ch
8 Channel8 ch
9 Channel9 ch
HSI 10ch10 ch
HSI 5ch5 ch
RGBW7 ch
RGBW 10ch10 ch
sRGWI7 ch
