Fuze Wash 500

Fuze Wash 500

Elation

#2749
Short Name: FuzW500

“The FUZE WASH 500™ is a powerful automated LED Fresnel wash fixture designed for theater, television, events and a wide array of other precision lighting applications. A High-CRI engine utilizes a 5-color homogenized LED array consisting of Red, Green, Blue, Mint, and Amber sources. The carefully tuned LEDs ensure accurate color reproduction while delivering a powerful output of up to 17,000 lumens and maximum CRI of 92. Virtual color temperature, Magenta / Green adjustment plus CMY or RGB emulation provide the designer with immediate access to the impressive LED color array. The FUZE WASH 500 is designed for any application where an automated Fresnel fixture with outstanding and impactful colors, a wide zoom range and a soft field is required. An optional indexable ovalizer lens and a fully automated barn door system is available for additional remote beam control.”

Physical

Weight18.5 kg
Length350 mm
Width408 mm
Height551 mm
IP RatingIP20
Temp Low-10°C
Temp High45°C

Electrical

Power Consump.600 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorXLR5 | RJ45 | PowerconTRUE1

Optical & Wheels

SourceFresnel
EmittersRed | Green | Blue | Mint | Amber
Lumens17,000 lm
CRI92
Zoom Min6°
Zoom Max53°
Color Wheels1 [61]
Gobo Wheels---

Movement

Pan Range540°
Tilt Range260°

Capabilities

PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel

DMX Modes

Standard14 ch
Extended18 ch
CMY Standard12 ch
CMY Extended16 ch
With Barndoor21 ch
