Gemini (CM 560Z)
ACME
#108Short Name: GEMINI
“Dual-functional LED bar and strobe moving fixture: front 5-cell 60W RGBW LED zoom color bar plus rear 36x18W cool-white LED strobe section with 18 individually controllable zones. Infinite pan/tilt rotation (not a fixed range).”
Physical
Weight19.5 kg
Length1000 mm
Width165 mm
Height315 mm
IP RatingIP20
Temp Low0°C
Temp High45°C
Electrical
Power Consump.650 W
Voltage100V - 240V
Frequency50Hz - 60Hz
ConnectorpowerCON, XLR3, XLR5
Optical & Wheels
SourceBar / Batten
EmittersRGBW (5x 60W RGBW LED + Dual Tilt Bar)
Lumens11,500 lm
CRI---
Zoom Min4°
Zoom Max45°
Color Wheels---
Gobo Wheels---
Movement
Pan Range---
Tilt Range220°
Capabilities
PanTiltZoomPrismFrostStrobeIrisFramingAnim. Wheel
DMX Modes
Standard23 ch
Extended51 ch
